Alfagomma Hydraulic® AlfaCrimp B Series B-0812-C61S 1-Piece Non-Skive Crimp Fitting, 1/2 in Hose x 3/4 in
NASHVILLE, TN
Available at All Branches
Alfagomma Hydraulic® AlfaCrimp 1-Piece Non-Skive Crimp Fitting, B Series, Straight Hose End Fitting Fitting, 1/2 in Connection Size 1, Connection Type 1: Hose, 3/4 in Connection Size 2, Connection Type 2: SAE Code 61 Flange, Hose|Flanged Connection, 08 Hose Dash, 42 mm Cut-Off Factor, For Use With: Up to 1 in ID Braided Hoses, Dimension Standards: SAE J518, 3000 psi Maximum Operating Pressure
| Connection Size 1 | : | 1/2 in |
| Connection Size 2 | : | 3/4 in |
| Connection Type 1 | : | Hose |
| Connection Type 2 | : | SAE Code 61 Flange |
| Connection Type | : | Hose|Flanged |
| Cut-Off Factor | : | 42 mm |
| Dimension Standards | : | SAE J518 |
| Fitting Type | : | Straight Hose End Fitting |
| For Use With | : | Up to 1 in ID Braided Hoses |
| Hose Dash Size | : | 08 |
| Maximum Operating Pressure | : | 3000 psi |
| Series | : | B Series |
