Gates® Truflex® 8400 Series 5L330 V-Belt, 5L Section, 32.92 in L Outside, 0.66 in W Top, 0.34 in Thick
NASHVILLE, TN
Available at All Branches
Truflex® belts are engineered with superior length stability for minimal take-up requirements, perfect for all industrial, light-duty applications, including fractional horsepower (FHP) motors and applications using backside idlers. Flex-bonded cords are strongly secured to the belt's body for equal load distribution and absorption of bending stress without cord deterioration. Gates® Curves provide proper cord support and full contact with the sheave-groove for uniform loading, uniform wear and increased belt life. The Flex-Weave® Cover is constructed for longer cover life, providing the belt's core with extended protection from oil, dirt and heat.
Gates® Truflex® V-Belt, Series: 8400 Series, 5L Section, 32.92 in Outside Length, 0.66 in Top Width, 0.34 in Thickness, 35 deg Angle, Resists: Heat, Oil, For Use With: Bored to Size, Bushed and Variable Pitch Light-Duty Sheaves
| Angle | : | 35 deg |
| Outside Length | : | 32.92 in |
| Resists | : | Heat, Oil |
| Section Size | : | 5L |
| Series | : | 8400 Series |
| Suitable For Use With | : | Bored to Size, Bushed and Variable Pitch Light-Duty Sheaves |
| Thickness | : | 0.34 in |
| Top Width | : | 0.66 in |
Specification Sheet
