In-line swivels rotating joints provide minimal friction allowing free movement of hoses and piping in fluid conducting power systems. The compact design fits in tight areas. Super Swivels® one-piece barrel and stem with integrated ball bearing race design withstands heavy side loads preventing premature seal wear and leaks. This pass-through inline design is the most standard configuration in live swivels. Super Swivels® connect directly to hose lines without adapters reducing overall costs of hydraulics. Inline sizes range from 1/8 to 2-1/2 in body thread with numerous fittings, finishes and seal configurations.
Super Swivels® In-Line Swivel, Fitting Type: Swivel, Connection Size 1: 1 in, Connection Type 1: Male 37 deg JIC, Connection Size 2: 1 in, Connection Type 2: Female 37 deg JIC, Material Construction: Carbon Steel, Zinc-Plated, 1-5/16-12 Thread, 1-3/8 x 1-3/4 in Hex, 4.091 in L x 1.917 in Dia, Maximum Operating Pressure: 4000 psig
| Connection Size 1 | : | 1 in |
| Connection Size 2 | : | 1 in |
| Connection Type 1 | : | Male 37 deg JIC |
| Connection Type 2 | : | Female 37 deg JIC |
| Connection Type | : | Male JIC|Female JIC |
| Dimensions | : | 4.091 in L x 1.917 in Dia |
| Finish | : | Zinc-Plated |
| Fitting Type | : | Swivel |
| Hex Size | : | 1-3/8 x 1-3/4 in |
| Material Construction | : | Carbon Steel |
| Material | : | Steel |
| Maximum Operating Pressure | : | 4000 psig |
| Thread Size | : | 1-5/16-12 |
- FKM seal
